# Linear Regression

## Principle

Linear regression algorithms are used for prediction purposes. An affine linear model makes a prediction by simply computing a weighted sum of the input features, plus a constant called the bias term (or intercept term)

$$\hat y = \theta_0 +\theta_1 x_1 +\theta_2 x_2 +\dots+ \theta_n x_n = \theta \cdot {\bf x} = h_\theta({\bf x}).$$

where $$\theta := (\theta_0,\dots,\theta_n)^T, \quad\quad {\bf x}:=(x_0,x_1,\dots,x_n)^T,\quad x_0=1.$$

• $n$ is the number of features.
• $x_i$ is the $i^{th}$ feature value.
• $h_\theta$ is the hypothesis function, using the model parameters $\theta$.
• $\hat y$ is the predicted value.

## Loss function

The MSE of hypothesis $h_\theta$ on a training set $\{(x^{(1)},y^{(1)}),\dots,(x^{(m)},y^{(m)})\} \subset \mathbb R^n \times \mathbb R$ is given by $$J(\theta) = MSE(X,h_\theta) = \frac 1{m} \sum_{i=1}^m ( h_\theta({\bf x}^{(i)}) - y^{(i)} )^2$$

If we introduce $X := (x^{(i)}_j)_{\substack{ 1 \leq i \leq m\\ 0 \leq j \leq n}} \in {\mathbb R}^{m \times (n+1)}$ and $Y :=(y^{(1)},\dots,y^{(m)})^T \in \mathbb R^m$, we have $$J(\theta)= \frac 1m \|X\theta-Y\|^2$$

We have $\nabla J(\theta):= \big(\frac{\partial J}{\partial \theta_0}(\theta),\dots \frac{\partial J}{\partial \theta_n}(\theta) \big)^T$ and the partial derivative of $J$ with respect to $\theta_j$ is

$$\frac{\partial J}{\partial \theta_j}(\theta)=\frac 1m\sum_{i=1}^m 2 x_j^{(i)} ( h_\theta({\bf x}^{(i)}) - y^{(i)} )$$

We have $$\nabla J(\theta):= \frac 1m 2 X^T (X\theta - Y)$$

The Batch gradient descent algorithm is given by

$$\theta^{(0)} \mbox{ initial guess},\quad \quad\quad \theta^{(k+1)}= \theta^{(k)} - \eta \nabla J(\theta^{(k)})$$

The whole batch $X$ of training data is used at every step.

The loss function is quadratic in $\theta$ (hence convex) and clearly L-smooth with

$$L=\frac 2m\|X^{T}X\|_{2\to2}= \frac 2m s_1(X)^2$$

where $s_1(X)$ is the largest singular value of $X$. Batch gradient descent with learning rate $\eta<1/L$ converge to $\theta^*$ which minimizes $J$.

Observe also that $J$ is minimized at $\theta^*$ for which $\nabla J(\theta^*)=0$. Hence, $\theta^*$ is solution of the normal equation
$$\theta^* = (X^T X)^{-1} X^TY$$

### Solving normal equation $(y=2+5x+\mbox{noise})$

In [7]:
## Direct computation using normal equation
%matplotlib inline
import numpy as np
import matplotlib.pyplot as plt
n,m = 1,200
x = 2* np.random.rand(m, n)
y = 2 + 5 * x + 0.5* np.random.randn(m, n) ## thus theta0= 2 , theta1=5
plt.scatter(x, y)
X_b = np.c_[np.ones((m, n)), x] # add x0 = 1 to each instance
theta_best = np.linalg.inv(X_b.T.dot(X_b)).dot(X_b.T).dot(y)
plt.plot([0,2],[theta_best[0],theta_best[0]+2*theta_best[1]],color='r')
print ('theta_best=',theta_best)
plt.show()

theta_best= [[1.98331783] [4.97826472]]


### Gradient descent for $(y=2+5x+\mbox{noise})$

In [8]:
## gradient descent applied to the function J: theta -> J (theta) ##
def val_f (theta):
return (1./m)*np.linalg.norm(X_b.dot(theta) - y)
return (2./m)*X_b.T.dot(X_b.dot(theta) - y)
x0 = np.zeros((2, 1))      # The algorithm starts at x0=(0,0)

s1 = np.linalg.norm(X_b, ord=2) ## Largest singular value of X_b
L = (2/m)*s1*s1            # L for L-smoothness
rate = 1./L                # Learning rate
precision = 0.001          # This tells us when to stop the algorithm
step_size = 1              # step being taken
max_iters = 4000           # maximum number of iterations
iters = 0                  #iteration counter

vec_x,vec_f  = [],[]
cur_x = x0
while step_size > precision and iters < max_iters:
vec_x = vec_x+[cur_x]
vec_f = vec_f+[val_f(cur_x)]
prev_x = cur_x                        #Store current x value in prev_x
step_size = np.linalg.norm(cur_x - prev_x)   #Change in x
iters = iters+1 #iteration count
print("The local minimum occurs at", vec_x[-1])
print("The local minimum is equal to", vec_f[-1])

The local minimum occurs at [[1.99344927] [4.96976563]]
The local minimum is equal to 0.035080866913785244


In [9]:
## Animation based on gradient descent applied for linear regression ##

import numpy as np
from matplotlib import pyplot as plt
from matplotlib.pyplot import figure
from matplotlib import animation, rc

#%matplotlib inline
#matplotlib notebook
#%matplotlib nbagg
%matplotlib tk

# First set up the figure, the axis, and the plot element we want to animate

fig = plt.figure()
fig.set_dpi(100)

xmin,xmax = 0, 2
fmin,fmax = 1,14

ax  = plt.axes(xlim=(xmin, xmax), ylim=(fmin, fmax))
line, = ax.plot([], [], lw=2,color='r')

# initialization function: plot the background of each frame
def init():
plt.scatter(x, y,color='b')
line.set_data([], [])
return line,

# animation function.  This is called sequentially
def animate(i):
a = [0,2]
theta= vec_x[i]
b = [theta[0],theta[0]+2*theta[1]]
line.set_data(a, b)
return line,

# call the animator.  blit=True means only re-draw the parts that have changed.
anim = animation.FuncAnimation(fig,
animate,
init_func=init,
frames=50,
interval=50,
blit=True)

# save the animation as an mp4.  This requires ffmpeg or mencoder to be
# installed.  The extra_args ensure that the x264 codec is used, so that
# the video can be embedded in html5.  You may need to adjust this for
# http://matplotlib.sourceforge.net/api/animation_api.html

#HTML(anim.to_html5_video())

from IPython.display import HTML
anim.save('GD_converge.mp4', fps=5, extra_args=['-vcodec', 'h264', '-pix_fmt', 'yuv420p'])
plt.show()


### Variants: interpretability, etc¶

• Lasso regression $$J(\theta) = \frac 1m \|X\theta-Y\|^2 + \lambda \|\theta\|_1$$
• Ridge regression $$J(\theta) = \frac 1m \|X\theta-Y\|^2 + \|\Gamma \theta\|^2$$
• Batch Gradient Descent scales well with the number of features However,
• Batch Gradient Descent can be terribly slow on very large training sets

$\Longrightarrow$ Gradient Descent algorithms

## Principle

We are interested in minimizing the additive loss function

$$J(\theta) = \sum_{i=1}^m J_i(\theta),\quad\quad\quad J_i(\theta):= ( h_\theta({\bf x}^{(i)}) - y^{(i)} )^2$$

One random instance $\{(x^{(\omega)},y^{(\omega)})\}$ in the training set is picked at every step $k$ and the gradient is computed based only on this instance. This gradient is $\nabla J_\omega(\theta) = \nabla_\theta J_\omega(\theta)$ and is equal to

$$\nabla J_\omega(\theta):= 2 (h_\theta({\bf x}^{(\omega)}) - y^{(\omega)}) {\bf x}^{(\omega)}.$$

The Stochastic Gradient Descent (SGD) algorithm for MSE minimization in linear regression is given by

$$\theta^{(0)} \mbox{ initial guess},\quad \quad\quad \left\{\begin{array}{} {\omega} \mbox{ randomly selected in} \{1,2,\dots,m\} \\ \theta^{(k+1)}= \theta^{(k)} - \eta \nabla J_{\omega}(\theta^{(k)}) \end{array} \right. \quad\quad\quad k\geq0.$$

Only one random instance $\{(x^{(\omega)},y^{(\omega)})\}$ of training data $X$ is used at every step.

• Every step $k$ of the algorithm is much faster.
• This makes it possible to train on large training sets.
In [10]:
n_epochs = 50
t0, t1 = 5, 50 # learning schedule hyperparameters
def learning_schedule(t):
return t0/(t+t1)

theta = np.random.randn(2,1) # random initialization
for epoch in range(n_epochs):
for i in range(m):
random_index = np.random.randint(m)
xi = X_b[random_index:random_index+1]
yi = y[random_index:random_index+1]
gradients = 2 * xi.T.dot(xi.dot(theta) - yi)
eta = learning_schedule(epoch * m + i)
theta = theta - eta * gradients

print(theta)

[[1.97779774] [4.97149486]]

### Using SGDRegressor

In [11]:
from sklearn.linear_model import SGDRegressor
sgd_reg = SGDRegressor(n_iter=50, penalty=None, eta0=0.1)
sgd_reg.fit(x, y.ravel())
sgd_reg.intercept_, sgd_reg.coef_

Out[11]:
(array([1.97771021]), array([4.960105]))

### Variant¶

• Mini-batch SGD
• Momentum
In [12]:
from IPython.display import IFrame
IFrame(src='https://arxiv.org/pdf/1609.04747.pdf', width=700, height=600)

Out[12]:

# Logistic Regression

## Principle

Logistic Regression (also called Logit Regression) algorithms are used for binary classification. The model estimates the probability that an instance belongs to one of two classes ({0,1} or {Y,N} or {+,-} etc) and predicts for the instance the class with the highest probability.

For classes $y$ in $\{0,1\}$, the model estimate a parameter $\theta= (\theta_0,\theta_1,\dots,\theta_n)^T\in {\mathbb R}^{n+1}$ and classifies (i.e. predicts the class) according to

$$\hat y = \left\{ \begin{array}{cc} 0 \quad \mbox{if}\quad \sigma(\theta.{\bf x})<0.5 \\ 1 \quad \mbox{if}\quad \sigma(\theta.{\bf x})\geq 0.5 \end{array} \right.$$

where $\sigma$ is the sigmoid function.

The number $\hat p:=\sigma(\theta.{\bf x})\in ]0,1[$ is an estimated probability that $x$ belongs to class $1$.

## Logistic function

Observe:

● $\sigma(\theta\cdot{\bf x})\geq0.5$ if and only if $\theta \cdot {\bf x}\geq 0$.
● $\sigma(\theta\cdot{\bf x})\lt0.5$ if and only if $\theta \cdot {\bf x} \lt 0$.

Observe:
$$\sigma'(t) = \sigma(t) (1- \sigma(t))$$

## Loss function

Here $\hat p=\sigma(\theta. {\bf x})$ and we introduce the misslasification error

$$c(\theta)=\left\{\begin{array}{l}- \log(\hat p)\quad &\quad y=1\\- \log(1- \hat p)\quad &\quad y=0\\ \end{array} \right. \quad\quad \equiv \quad\quad c(\theta) =-\bigg[\log(\hat p) y+ \log(1- \hat p) (1-y)\bigg]$$

This error is intuitive

$-\log(\hat p)=\log(1/{\hat p})$ grows very large when $\hat p$ approaches $0$. The loss (or penalty) is large if the model estimates a probability close to $0$ for instance in class $1$.
$-\log(1-\hat p)$ is close to $0$ when $\hat p$ approaches $0$. The loss (or penalty) is small if the model estimates a probability close to $0$ for instance in class $0$. (Same observations if $\hat p$ approaches $1$).

Given a training set $\{(x^{(1)},y^{(1)}),\dots,(x^{(m)},y^{(m)})\} \subset \mathbb R^n \times \mathbb \{0,1\}$, the loss function is given by

$$J(\theta) = \frac 1{m} \sum_{i=1}^m c^{(i)}(\theta),\quad\quad\quad c^{(i)}(\theta)=-\bigg[\log(\hat p^{(i)}) y^{(i)} + \log(1- \hat p^{(i)}) (1-y^{(i)})\bigg]$$

This loss function is called negative log-likelihood/binary cross entropy/log loss [a visual explanation]

Given $c(\theta) =-\big[\log(\hat p) y+ \log(1- \hat p) (1-y)\big]$, observe $$\frac {\partial c }{\partial \theta_j} =\frac {\partial c }{\partial \hat p }\frac {\partial \hat p }{\partial (\theta.{\bf x})}\frac {\partial (\theta.{\bf x})}{\partial \theta_j } =\frac {\partial c }{\partial \hat p }\;\sigma'(\theta.{\bf x})\;x_j$$ We have $$\frac {\partial c }{\partial \hat p } = -\bigg[\frac 1 {\hat p} y - \frac 1{1- \hat p} (1-y)\bigg]\quad\quad\sigma'(\theta.{\bf x})\;= \sigma (\theta.{\bf x}) (1-\sigma(\theta.{\bf x})) = \hat p (1- \hat p)$$ Finally $$\frac {\partial c }{\partial \theta_j}=-\bigg[(1- \hat p) y - \hat p (1-y)\bigg]x_j=\big[ \hat p -y \big]x_j$$

The partial derivatives of $J$ are given by $$\frac {\partial J(\theta) }{\partial \theta_j}=\frac 1{m} \sum_{i=1}^m \frac {\partial c^{(i)}(\theta) }{\partial \theta_j}=\frac 1{m} \sum_{i=1}^m \big[ \sigma(\theta.{\bf x}^{(i)})-y^{(i)} \big]\;x_j^{(i)}$$

Chain rule: seed to Back-propagtion algorithms

### Decision Boundaries for the iris flower dataset¶

In [13]:
from sklearn import datasets
list(iris.keys())

Out[13]:
['data', 'target', 'target_names', 'DESCR', 'feature_names', 'filename']
In [14]:
iris['feature_names']

Out[14]:
['sepal length (cm)',
'sepal width (cm)',
'petal length (cm)',
'petal width (cm)']
In [15]:
from sklearn.linear_model import LogisticRegression

X = iris["data"][:, (2, 3)]  # petal length, petal width
y = (iris["target"] == 2).astype(np.int)

log_reg = LogisticRegression(C=10**10, random_state=42)
log_reg.fit(X, y)

x0, x1 = np.meshgrid(np.linspace(2.9, 7, 500).reshape(-1, 1),
np.linspace(0.8, 2.7, 200).reshape(-1, 1),)
X_new = np.c_[x0.ravel(), x1.ravel()]

y_proba = log_reg.predict_proba(X_new)

plt.figure(figsize=(10, 4))
plt.plot(X[y==0, 0], X[y==0, 1], "bs")
plt.plot(X[y==1, 0], X[y==1, 1], "g^")

zz = y_proba[:, 1].reshape(x0.shape)
contour = plt.contour(x0, x1, zz, cmap=plt.cm.brg)

left_right = np.array([2.9, 7])
boundary = -(log_reg.coef_[0][0] * left_right + log_reg.intercept_[0]) / log_reg.coef_[0][1]

plt.clabel(contour, inline=1, fontsize=12)
plt.plot(left_right, boundary, "k--", linewidth=3)
plt.text(3.5, 1.5, "Not Iris-Virginica", fontsize=14, color="b", ha="center")
plt.text(6.5, 2.3, "Iris-Virginica", fontsize=14, color="g", ha="center")
plt.xlabel("Petal length", fontsize=14)
plt.ylabel("Petal width", fontsize=14)
plt.axis([2.9, 7, 0.8, 2.7])
save_fig("logistic_regression_contour_plot")
plt.show()


In logistic regression, the model find the "best" parameter $\theta$ for which the hyperplane $\theta.{\bf x}=0$ (dashed black line above) "best" divides training set into the two classes.

# Softmax regression

## Principle

Softmax regression generalizes logistic regression in order to support $K$ classes. The model estimates a parameter matrix

$$\Theta = [\Theta_1|\Theta_2\dots|\Theta_K]^T\in {\mathbb R}^{K \times (n+1)},\quad\quad \Theta_k =(\Theta_{0,k},\Theta_{1,k},\dots,\Theta_{n,k} )^{T}.$$

Given $x\in{\mathbb R}^n$ and ${\bf x} = (1,x) \in {\mathbb R}^{n+1}$, we compute $z=\Theta {\bf x}~$ ( i.e. $z_j=\Theta_j. {\bf x}$ for every $j=1,\dots,K$), then compute the $K$ probabilities

$$\hat p_k = \frac {\exp({z_k})}{\displaystyle\sum_{j=0}^K \exp({z_j})},\quad\quad k=1,\dots,K. \label{hatp_softmax}$$

The class predicted for $x$ is the class $k$ with the highest probabilities $\hat p_k$.

## Loss function

Here $\hat p$ is as in \eqref{hatp_softmax} and we introduce the misslasification error for $(x,y)$ by

$$c(\Theta)= - \log (\hat p_k), \quad\quad \mbox{if}\quad\quad y = k.$$

Intuitively, given $(x,y)$ with $y$ belongs to class $k$

• we want $c(\Theta)$ to be close to $0$, implying $\hat p_k$ close to $1$ (so that $\hat p_k$ is the highest probability).
• the closer $\hat p_k$ is to $0$ (i.e. the more certain that a miss-classification occurs), the larger is the loss (penalization) $c(\Theta)$.

Given a training set $\{(x^{(1)},y^{(1)}),\dots,(x^{(m)},y^{(m)})\} \subset \mathbb R^n \times \mathbb \{1,2,\dots,K\}$, the loss function is given by

$$J(\Theta)= \frac 1{m} \sum_{i=1}^m c^{(i)}(\Theta)=- \frac 1{m} \sum_{i=1}^m \log (\hat p_{y^{(i)}}^{(i)}).$$

We will view the function $J$ as a function of $(\Theta_1,\Theta_2,\dots,\Theta_K)$.

We let $\theta = \Theta_{j} \in \mathbb R^{n+1}$ for some $j\in \{1,\dots,K\}$: we have the following function dependency diagram

$$\Theta \longrightarrow (z^{(i)}_l)_{\substack{i=1,\dots,m\\l=1,\dots,K}} \longrightarrow J.$$

Using chain rule with respect to these intermediates variables and $\nabla_{\theta} z_l = \delta_{j,l}{\bf x}$ which follows from $z_l=\Theta_l. {\bf x}$,

$$\nabla_{\theta} J(\Theta)=\sum_{i=1}^m \sum_{l=1}^K\frac {\partial J(\Theta)}{\partial z_l^{(i)}}\nabla_{\theta} z_l^{(i)}=\sum_{i=1}^m \frac {\partial J(\Theta)}{\partial z_j^{(i)}}{\bf x}^{(i)}$$

In view of the formula for $J$, for $i$ such that $y^{(i)}=k$ holds

$$\frac {\partial J(\Theta)}{\partial z_j^{(i)}}= -\frac 1m \frac {\partial \log(\hat p_k^{(i)})}{\partial z_j^{(i)}}$$

By derivation of usual functions, one has

$$\frac {\partial \log(\hat p_k)}{\partial z_j} =\frac 1{\hat p_k} \frac {\partial \hat p_k}{\partial z_j} = \frac 1{\hat p_k} \left\{ \begin{array}{ll} \hat p_k - (\hat p_k)^2&\quad \mbox{if}\quad j=k \\ - \hat p_k \hat p_j &\quad \mbox{if}\quad j\neq k \end{array} \right. = \left\{ \begin{array}{ll} 1 - \hat p_k&\quad \mbox{if}\quad j=k \\ - \hat p_j &\quad \mbox{if}\quad j\neq k \end{array} \right.$$

The combination of the previous formulas implies that $J$ as a function of $(\Theta_1,\Theta_2,\dots,\Theta_K)$ satisfies

$$\nabla_{\Theta_j} J(\Theta) = - \frac 1m \sum_{i=1}^m ({\mathbb 1}_{y^{(i)}=j} - \hat p_j^{(i)}) {\bf x}^{(i)} \quad\quad\quad\quad \nabla_{\Theta_j} J(\Theta) \in {\mathbb R}^{n+1}.$$

Finally

$$\nabla_{\Theta} J(\Theta) = [\nabla_{\Theta_1} J(\Theta) |\nabla_{\Theta_2} J(\Theta) |\dots|\nabla_{\Theta_k} J(\Theta) ]^T\in {\mathbb R}^{K \times (n+1)}.$$

can all be implemented.

In [17]:
X = iris["data"][:, (2, 3)]  # petal length, petal width, mainly for visualisation
y = iris["target"]

softmax_reg = LogisticRegression(multi_class="multinomial",solver="lbfgs", C=10, random_state=42)
softmax_reg.fit(X, y)
#lbfgs: Limited-memory Broyden–Fletcher–Goldfarb–Shanno algorithm.

x0, x1 = np.meshgrid( np.linspace(0, 8, 500).reshape(-1, 1),
np.linspace(0, 3.5, 200).reshape(-1, 1),)
X_new = np.c_[x0.ravel(), x1.ravel()]

y_proba = softmax_reg.predict_proba(X_new)
y_predict = softmax_reg.predict(X_new)

zz1 = y_proba[:, 1].reshape(x0.shape)
zz = y_predict.reshape(x0.shape)

plt.figure(figsize=(10, 4))
plt.plot(X[y==2, 0], X[y==2, 1], "g^", label="Iris-Virginica")
plt.plot(X[y==1, 0], X[y==1, 1], "bs", label="Iris-Versicolor")
plt.plot(X[y==0, 0], X[y==0, 1], "yo", label="Iris-Setosa")

from matplotlib.colors import ListedColormap
custom_cmap = ListedColormap(['#fafab0','#9898ff','#a0faa0'])

plt.contourf(x0, x1, zz, cmap=custom_cmap)
contour = plt.contour(x0, x1, zz1, cmap=plt.cm.brg)
plt.clabel(contour, inline=1, fontsize=12)
plt.xlabel("Petal length", fontsize=14)
plt.ylabel("Petal width", fontsize=14)
plt.legend(loc="center left", fontsize=14)
plt.axis([0, 7, 0, 3.5])
save_fig("softmax_regression_contour_plot")
plt.show()


## Summary

How do we learn the "best" weights vector $(\theta_0^*,\dots,\theta_n^*)$ or matrix $(\Theta_0^*|\dots|\Theta_n^*)$ in linear/logistic/softmax regression

• Give weights random initial values

• Evaluate partial derivative of each weight with respect to MSE or negative log-likelihood at current weight value

• Take a step in direction opposite to the gradient

• Rinse and repeat

Essence of the entire learning process behind deep learning algorithms

# Neural network and backpropagation

## MULTILAYER PERCEPTRONS (MLPs)

• Most generic form of a neural net is the "multilayer perceptron"
• Input undergoes a series of nonlinear transformation
• A final classification layer
• MLPs are easy entry to understand deep learning models
• Closely related to logistic/softmax regression

## Principle

We consider classification problem for iris dataset using neural network with one hidden layer (5 nodes) and activation function $\varphi$ (sigmoid, ReLU, etc)

- Input layer

$$x=(x_1,x_2,x_3,x_4)^T.$$

- Hidden layer

$$h = (h_1,h_2,h_3, h_4,h_5)^T.$$

- Output layer

$$z = ( z_1, z_2, z_3)^T.$$

With bias in input and hidden layer $x_0 = 1, h_0=1$, we denote

$${\bf x} = (1,x^T)^T,\quad\quad\quad {\bf h} = (1,h^T)^T$$

## Loss function

As for softmax regression, the model minimizes the negative log-likelihood loss function associated with the training set $\{(x^{(1)},y^{(1)}),\dots,(x^{(m)},y^{(m)})\} \subset \mathbb R^n \times \mathbb \{1,2,\dots,K\}$ ($n=4$ and $K=3$ for iris dataset)

$$J(\widetilde\Theta,\Theta) = - \frac 1{m} \sum_{{i=1}}^m \log (\hat p_k^{(i)}),\quad\quad\quad (k \mbox{ is such that } y^{(i)} \mbox{ belongs to class } k),$$

in order to find the best parameter matrices $\widetilde\Theta^*$ and $\Theta^*$.

If $n_h$ is the number of nodes in the hidden layer (here $n_h=5$), we write

$$\widetilde\Theta = [\widetilde\Theta_1|\widetilde\Theta_2\dots|\widetilde\Theta_{n_h}]^T\in {\mathbb R}^{n_h \times (n+1)},\quad\quad \Theta = [\Theta_1|\Theta_2\dots|\Theta_K]^T\in {\mathbb R}^{K \times (n_h+1)},\quad\quad$$

We will view the function $J$ as a function of $(\widetilde\Theta_1,\widetilde\Theta_2,\dots,\widetilde\Theta_{n_h},\Theta_1,\Theta_2,\dots,\Theta_K)$.

We recall the mapping diagram

$${\bf x} \quad\Longrightarrow\quad h^{-} = \widetilde \Theta {\bf x} \quad\Longrightarrow\quad h = \varphi(h^{-}) \quad\Longrightarrow\quad z=\Theta {\bf h}$$

and the function dependency diagram

$$(\widetilde \Theta, \Theta) \longrightarrow ({h^{-}_j}^{(i)})_{\substack{i=1,\dots,m\\j=1,\dots,n_h}} \longrightarrow ({h_j}^{(i)})_{\substack{i=1,\dots,m\\j=1,\dots,n_h}} \longrightarrow (z^{(i)}_l)_{\substack{i=1,\dots,m\\l=1,\dots,K}} \longrightarrow J.$$

- For $j=1,\dots,K$, we proceed as in soft-max regression (but as if $h$ is the input)

$$\nabla_{\Theta_j} J =\sum_{i=1}^m \frac {\partial J}{\partial z_j^{(i)}}{\bf h}^{(i)} = - \frac 1m \sum_{i=1}^m ({\mathbb 1}_{y^{(i)}=j} - \hat p_j^{(i)}) {\bf h}^{(i)}.$$

Observe dependance on $\widetilde\Theta$ through the ${\bf h}^{(i)}$ then on $\Theta$ through the $\hat p_k^{(i)}$.

- For $j = 1,\dots,n_h$ and $\tilde\theta = \widetilde\Theta_{j}$, we proceed as in softmax regression: chain rule with variables $({h_l^{-}}^{(i)})_{\substack{i=1,\dots,m\\l=1,\dots,n_h}}$ and $h^{-} = \widetilde \Theta {\bf x}$ implies

$$\nabla_{\tilde\theta} J= \sum_{i=1}^m \sum_{l=1}^{n_h}\frac {\partial J}{\partial {h_l^{-}}^{(i)}} \nabla_{\tilde\theta} {h_l^{-}}^{(i)}= \sum_{i=1}^m \frac {\partial J}{\partial {h_j^{-}}^{(i)}} {\bf x}^{(i)}.$$

Then $\frac {\partial J}{\partial {h_j^{-}}^{(i)}} =\frac {\partial J}{\partial h_j^{(i)}} \varphi'({h_j^{-}}^{(i)})$ and

$$\frac {\partial J}{\partial h_j^{(i)}} = \sum_{l=1}^K \frac {\partial J}{\partial z_l^{(i)}} \frac {\partial z_l^{(i)}}{\partial h_j^{(i)}} = \sum_{l=1}^K \frac {\partial J}{\partial z_l^{(i)}} \Theta_{j,l}.$$

The gradients $\nabla_{\Theta} J$ and $\nabla_{\widetilde\Theta} J$ are completely determined if we know (compute)

$$\frac{\partial J}{\partial z_j^{(i)}} \quad \substack{i=1,\dots,m,\\ j=1,\dots K} \quad\quad\quad \frac{\partial J}{\partial h_j^{(i)}} \quad \substack{i=1,\dots,m,\\ j=1,\dots n_h}.$$

Gradient descent and variations can be implemented

## Backpropagation

- Forward pass: given $\widetilde\Theta$ and $\Theta$, compute $${h^-}^{(i)},\; {h}^{(i)}, \; {z}^{(i)}\quad\quad i=1,\dots,m.$$ Then compute $$J(\widetilde\Theta,\Theta).$$

- Backpropagate errors: compute $$\nabla_{{z}^{(i)}} J,\; \nabla_{{h}^{(i)}} J,\; \nabla_{{h^-}^{(i)}}J, \quad\quad i=1,\dots,m.$$ Then compute $$\nabla_{\Theta} J,\;\nabla_{\widetilde\Theta} J.$$

The generalization to multiple hidden layer is straightforwad, see online free book

The same approach applies if

• many hidden layer
• $J$ is another loss function

in which case, one wants to minimize

$$J(\Theta_1,\Theta_2,\dots) + \lambda_1 {\rm tr}(\Theta_1^T \Theta_1)+\lambda_2 {\rm tr}(\Theta_2^T \Theta_2)+ \dots$$

Training a Neural Network

• Randomly initialize the weights matrices,
• Implement forward propagation to get the output $z^{(i)}$ for any input $x^{(i)}$;
• Implement the loss function;
• Implement backpropagation to compute partial derivatives;
• Use gradient descent or a built-in optimization function to minimize the loss function
• Output weights matrices $\Theta_1^*,\;,\Theta_2^*,\dots$

## tensorflow code

In [18]:
import tensorflow as tf
with tf.name_scope("dnn"):
hidden1 = neuron_layer(X, n_hidden1, "hidden1", activation="relu")
hidden2 = neuron_layer(hidden1, n_hidden2, "hidden2", activation="relu")
logits = neuron_layer(hidden2, n_outputs, "outputs")
